Introduction
The ZX6350C Drilling and Milling Machine is a heavy-duty drilling and milling machine designed for reliable metal machining operations. This model integrates drilling, tapping, and milling functions, making it a practical solution for workshops requiring versatility and stable performance.
Compared with smaller drilling machines, the ZX6350C features a reinforced machine structure and higher machining capacity, allowing it to handle tougher materials and more demanding machining tasks. It is widely used in mechanical workshops, maintenance facilities, and small-scale production environments.
Specification
|
SPECIFICATION |
ZX6350C |
| Maximum drilling diameter (mm) | 50 |
| Maximum width of end milling (mm) | 120 |
| Maximum diameter of vertical milling (mm) | 25 |
| Maximum tapping diameter (mm) | M16 |
| Distance from spindle to worktable (mm) | 100-500 |
| Spindle speed (vertical/horizontal) (r.p.m.) | 34-1750/40-1300 (horizontal) |
| Spindle stroke (mm) | 120 |
| Workbench size (mm) | 1200 × 280 |
| Workbench travel approximately (mm) | 600 × 280 |
| Dimensions (mm) | 1860 × 1540 × 2250 |
| Motor power (standing/lying) (kw) | 1.5/2.2; 2.2 |
| Net weight/gross weight (kg) | 1200/1400 |
| Maximum drilling diameter (mm) | 50 |
Standard Accessory
- Mechanical knife feeder
- Two axis DRO
- Slotting head 1.1kw, travel 125mm
Terms
- Voltage: 3PH, 380V, 50HZ/ 3PH, 220V,60HZ
- Original: CHINA
- Delivery time: 20—30 days from CHINA
- We’re Milling Machine CHINA Factory, welcome contact us for latest quotation, thank you!
