X6336 Milling Machine with pneumatic head 1500x360mm

Introduction

The X6336 Milling Machine with Pneumatic Head is a heavy-duty milling machine designed for efficient and stable metal machining. Equipped with a pneumatic head system, this model allows smooth and responsive head movement, improving operational efficiency and machining convenience.

With a large working table size of 1500 × 360 mm, the X6336 is suitable for machining longer and wider workpieces. Its robust structure and practical design make it ideal for production workshops, tooling departments, and industrial maintenance applications.

Specification

Spindle power	5HP Vertical
	4KW Horizontal
Spindle speed	Vertical 66-5440rpm (16 gear)
	Horizontal 60-1800rpm, (12 gear)
Spindle taper	NT40 Vertical
	7：24ISO50 Horizontal
Spindle sleeve automatic feed stage	3 levels/0.04/0.08/0.15mm/r
Workbench longitudinal and transverse motorized feed speed	level 8, 15~370mm/min (fast forward 540mm/min optional)
Vertical lifting speed of workbench	590mm/min
Workbench area	1500 × 360mm
Workbench travel X/Y/Z axis	1000/320/350mm
Workbench T-slot	3/16/65
Distance from the center of the vertical spindle to the surface of the column	150-550mm
Distance from the end face of the vertical spindle to the workbench	135-485mm
Distance from the center of the horizontal spindle to the workbench	0-350mm
The distance from the center of the horizontal spindle to the lower plane of the ram	30mm
Vertical spindle travel	127mm
Workbench motorized feed motor power	750W
Power of the mobile lifting motor of the lifting platform	1.1KW
Cooling pump motor power	90W
Machine size (L*W*H)	2220x1790x2360mm
Machine weight	2500kg



Free Equipped

Optional Accessory



Terms

• Voltage:  3PH, 380V, 50HZ/ 3PH, 220V,60HZ
• Condition:   100% New
• Original: CHINA
