No.4HW Turret Milling Machine with Horizontal Head 1270X254 mm

Introduction

The NO.4HW Turret Milling Machine with Horizontal Milling Head is a versatile milling solution designed for workshops requiring both turret milling flexibility and horizontal milling capability. By integrating a horizontal milling head, this model allows users to perform a wider range of machining operations on a single machine.

This machine is suitable for processing flat surfaces, slots, keyways, and structural components, offering practical versatility for tooling, maintenance, and small batch production environments

Specification



(1) NO.4- NO.5 Turret Milling Machine —–  (Vertical)

SPECIFICATIONS	UNIT	NO.4	NO.5
Table size	mm	1270*254	1370*305
Table travel	mm	780/400/400	810/400/400
T slot(number-width*pitch)		3-16*50	3-16*65
Spindle taper		R8(Optional opt.ISO40)
Spindle speed range(steps)	rpm	50HZ:65-4500,60HZ:80-5440(16) (Optional opt. No segment (variable)65-4000)
Spindle travel	mm	127	127
Spindle feed range(steps)	mm	0.045,0.086,0.142 (3)	0.045,0.086,0.142 (3)
Distance between spindle nose and table surface	mm	90-510	90-510
Main motor power	rpm	2.2	2.2
Head rotation(left-right )		±90°	±90°
Head rotation(front -rear)		±45°	±45°
Machine weight	kg	1400	1600
Overall dimension	mm	1550*1650*2250	1550*1650*2250

(2) 4HW- 5HW Turret Milling Machine —–  (Vertical & Horizontal )

SPECIFICATIONS	UNIT	4HW	5HW
Table size	mm	1270*254	1370*305
Table travel	mm	780/400/400	810/400/400
T slot(number-width*pitch)		3-16*50	3-16*65
Spindle taper		R8(Optional opt.ISO40)
Horizontal Spindle taper		ISO40
Spindle speed range(steps)	rpm	50HZ:65-4500,60HZ:80-5440(16) (Optional opt. No segment (variable)65-4000)
Horizontal speed range(steps)		45-1350 (12)
Spindle travel	mm	127	127
Spindle feed range(steps)	mm	0.045,0.086,0.142 (3)	0.045,0.086,0.142 (3)
Distance between spindle nose and table surface	mm	90-510	90-510
Distance between horizontal spindle axis and table surface	mm	0-400
Main motor power	rpm	2.2 Vertical/ 3 Horizontal	2.2 Vertical/ 3 Horizontal
Head rotation(left-right )		±90°	±90°
Head rotation(front -rear)		±45°	±45°
Machine weight	kg	1750	1850
Overall dimension	mm	1550*1650*2250	1550*1650*2250



Optional Accessory



1. 3 axis DRO
2. Automatic feed
3. Electronic oil pump
4. Clamping kit
5. Pneumatic draw bar
6. Dividing head
7. Tools



Terms

• Voltage:  3PH, 380V, 50HZ/ 3PH, 220V,60HZ
• Condition:   100% New
• Original: CHINA
