Introduce
The CK61160 CNC Lathe Machine is an extra heavy-duty flat bed CNC lathe engineered for machining extremely large and heavy workpieces. With a 63-inch swing over bed and 80-inch distance between centers, this machine is designed to handle oversized components that require maximum rigidity and stable CNC turning performance.
This model is especially suitable for industries such as energy equipment, heavy machinery manufacturing, shipbuilding, and large structural component production, where precision and reliability are critical under high-load cutting conditions.
Main Parameter
-Diameter 1600mm
-Length 1000mm/1500mm/2000mm/3000mm/4000mm
-Spindle hole diameter 105/130mm
-CNC system GSK/FANUC/SIEMENS
– Vertical 4 station tool post, 6 station/8 station for optional
Condition
-100% New
-Origin CHINA
Specification
| Item | Unit | CK61160 |
| Maximum rotary diameter of the bed | mm | 1600 |
| Width of bed guideway | mm | 755 |
| Maximum cutting length | mm | 2000 |
| Maximum cutting diameter | mm | 1600 |
| Spindle end type and code | — | A2-15 |
| Spindle hole diameter | mm | 130mm |
| Maximum rotary diameter on tool holder | mm | 1100 |
| Spindle speed range | r/min | 10-315 |
| Number of spindle speed stages | — | Manual four speed/stepless speed regulation within gears |
| Main motor | kw | 22KW main servo motor |
| X-axis travel | mm | 1400 |
| Z-axis travel | mm | 2000 |
| Tailstock sleeve diameter | mm | 180 |
| Tailstock sleeve travel | mm | 300 |
| Tailstock spindle taper | — | Metric 80, 1:20 |
| Center height Distance to bed | mm | 625 |
| CNC control system | — | GSK980TDI |
| Chuck | mm | 1250 |
| Voltage | mm | 3PH,380v,50hz |
Free Equipped
-GSK980TDi CNC System
-Spindle through bore diameter 130mm
-Electrical tailstock
-Tailstock equipped with change speed
-Automatic lubrication
-Working light
-4-position tool post 300*300mm
-Main motor 22kw
-4-jaw chuck diameter 1250mm
-Bed guide width 755mm
-Capacity max. 6000 kg
-Voltage/ Frequency 380V; 50Hz, 3 Phase
