XH1040 CNC Milling Machine 1250*360mm BT40 5.5kw
XH1040 CNC Milling Machine 1250*360mm BT40 5.5kw
The XH1040 CNC milling machine focuses on compact size and precision machining, making it an ideal alternative to larger bed type CNC milling machines when space efficiency and accuracy are priorities.
Share：
Product Description
Introduction
The XH1040 CNC Milling Machine is a compact CNC milling solution designed for precise and efficient metal machining. Featuring a rigid machine structure and a BT40 spindle, this model provides a balance between machining accuracy and operational efficiency.
With a working table size of 1250 × 360 mm and a 5.5 kW spindle motor, the XH1040 is suitable for small to medium-sized workpieces. It is widely used in general manufacturing, tooling production, and component machining applications where space efficiency and CNC precision are required.
Specification
| NO. | ITEM | Specification | ||
| 1 | Table size L(mm)×W(mm) | 1250*360 | ||
| 2 | T slot QTY /width/interval distance(mm) | 3-14-80 | ||
| 3 | Maximum load(KG) | 350 | ||
| 4 | X travel (mm) | 900/1000（Optional） | ||
| 5 | Y travel (mm) | 400 | ||
| 6 | Z travel (mm) | 500 | ||
| 7 | Spindle nose to table (mm) | 100-600 | ||
| 8 | Spindle center to column (mm) | 460 | ||
| 9 | Spindle taper | BT40/120 | ||
| 10 | Spindle driver | Direct | ||
| 11 | Max. spindle speed (Rpm) | 8000 | ||
| 12 | Main motor（kW） | 5.5 | ||
| 13 | Feed motor | X torque（N.M） | 7.7 | |
| Y torque（N.M） | 7.7 | |||
| Ztorque（N.M） | 10 | |||
| Max. install size | 5.5 | |||
| 14 | Rapid moving speed (m/min.） | 8/8/8 | ||
| 15 | Cutting speed（mm/min） | 1-4000 | ||
| 16 | Ball screw（diametermm/pitch）mm | X32/06 YZ4006 | ||
| 17 | Accuracy | Positioning accuracy (mm) | 0.016 | |
| Repeatability accuracy (mm) | 0.008 | |||
| 18 | Air pressure Mpa | 0.6 | ||
| 19 | Machine weight(kg) | 2500 | ||
| 3000 | ||||
| 20 | Machine overall size : L(mm)×W(mm)×H(mm) | 2220x1860x2280 | ||
Terms
Voltage: 3PH, 380V, 50HZ/ 3PH, 220V,60HZ
Condition: 100% New
Original: CHINA
Free Acceesory
| NO. | ITEM | SPECIFICATION | QTY | NOTE |
| 1 | Spring clip handle | MAS BT40-ER32 | 1 | |
| 2 | Card spring | 6、8、10、12、16、20 | Each 1 | |
| 3 | Pull the nail | P40T-1-MAS403 | 1 | |
| 4 | Adjustable shim and bolt | 1 set |
