*Precision ground and hardened bedways
*The spindle is supported with precision roller bearings
*Head stock gears are made of high quality steel ground and hardened
*Three diferent length beds are available
*Spindle speed range 70-2000r/min D1-4 cam lock spindle nose*ф51mm Spindle bore for optional
*Two speed motor for optional
DRO 2 Axis
DRO 3Axis
Taper turning attachment
Live center
Knife holder cover
Screw rod cover
| 床身上最大工件回转直径 Swing Over Slide | 330mm(13″) |
| 中心高度Center Height | 166mm(6-1/2″) |
| 两顶尖间最大距离Distance Between Centers | 1000mm(40″) |
| 床面宽度Width of Bed | 187mm(7-3/8″) |
| 床面长度 lenght of lathe | 1655mm(65-1/8″) |
| 床面高度 heigjt of lathe | 290mm（11- 13/32″） |
| 主轴孔径Spindle Bore | 38mm(1-1/2″) |
| 主轴端部 spindle nose | D1-4″ |
| 主轴端部推拔 Spindle Nose | MT NO.5 |
| 套筒推拔 Quill taper | MT NO.3 |
| 主轴速度变换数Spindle Speed Number | 8 |
| 主轴转速范围Range of Spindle Speed | 70-2000 r/min |
| 滑板宽度Width of Cross Slide | 130mm（5-3/32″） |
| 滑板行程Max. Travel of Cross Slide | 170mm(6-11/16″) |
| 复式刀架滑板宽度 | 80mm(3-1/8″) |
| 复式刀架滑板行程Max. Travel of Compound Rest | 95mm(3-9/16″) |
| 床鞍导杆外径 | 22mm(7/8″) |
| 床鞍导杆螺距Leadscrew Pitch | 8T.P.I. or 3mm |
| 进给杆外径 | 19mm(3/4″) |
| 加工刀具端面最大尺寸Max. Section of Tool | 16mm×16mm(5/8″×5/8″) |
| 英制螺距Inch Threads Range | 34 Nos.4-56 T.P.I |
| 公制螺距Metric Threads Range | 26 Nos.0.4-7 M.P |
| 纵向进给英制Longitudinal Feeds Range in Inch Lead Screw | 32 Nos.0.002-0.548″/Rev |
| 纵向进给公制Longitudinal Feeds Range in Metric Lead Screw | 32 Nos.0.052-0.392mm/Rev |
| 横向进给英制Cross Feeds Range in Inch Lead Screw | 32 Nos.0.007-0.0187″/Rev) |
| 横向进给公制Cross Feeds Range in Metric Lead Screw | 32 Nos.0.014-0.380mm/Rev |
| 套筒直径Quill diameter | 32mm(1-1/4″) |
| 套筒行程Quill travel | 100mm(3-15/16″) |
| 套筒锥度Quill taper | MT NO.3 |
| 主电机Main motor power | 1.5Kw(2HP) |
