The CK6163 Flat Bed CNC Lathe Machine is a heavy-duty CNC turning solution with a 630 mm swing over bed, 1000 mm distance between centers, 82 mm spindle bore, and 7.5 kW main motor. Designed for large-diameter shafts, flanges, discs, hubs, and other heavy industrial components.
Product Specifications
- Swing Over Bed: 630 mm
- Distance Between Centers: 1000 mm
- Spindle Bore: 82 mm
- Spindle Motor: 7.5 kW
- CNC Control System: GSK
- Tool post: Horizontal six station tool post
Product Overview
The CK6163 Flat Bed CNC Lathe Machine (25″x40″ / 630x1000mm) is engineered for heavy-duty turning of large-diameter shafts, flanges, discs, hubs, and other cylindrical components. With a rigid flat bed structure, 630 mm swing over bed, and precision spindle system, it provides strong rigidity, stable cutting performance, and reliable CNC machining for demanding industrial applications.
This flat bed CNC lathe machine combines large turning capacity with a relatively compact 1000 mm center distance, making it particularly suitable for thick and heavy workpieces that require high rigidity and stable material removal.
Φ 630 mm (25″)
1000 mm (40″)
Φ 82 mm (3.23″)
GSK / FANUC / Siemens
Technical Specifications
| Specification Item | Metric Unit | Imperial Unit |
|---|---|---|
| Model | CK6163 | CK6163 |
| Swing Over Bed | Φ 630 mm | 25″ |
| Distance Between Centers | 1000 mm | 40″ |
| Spindle Bore Diameter | Φ 82 mm | 3.23″ |
| Main Motor Power | 7.5 kW | 10 HP |
| Spindle Speed Range | 60–1600 / 50–2000 rpm | 60–1600 / 50–2000 rpm |
| Tool Post Type | 6-Station Electric Tool Post | 6-Station Electric Tool Post |
| X / Z Axis Rapid Traverse Rate | 6 / 8 m/min | 236 / 315 ipm |
| Tailstock Quill Diameter | Φ 85 mm | 3.35″ |
Structural Features & Premium Components
- Heavy-Duty Flat Bed Structure: The CK6163 adopts a rigid flat bed design with strong vibration damping capability, providing stable cutting performance when machining large-diameter and heavy workpieces.
- Large-Diameter Turning Capacity: With a maximum swing over bed of 630 mm, the machine is designed for turning large shafts, flanges, discs, hubs, and other cylindrical components requiring high rigidity.
- High-Precision Spindle System: The 82 mm spindle through-hole provides useful machining capacity for medium and large workpieces while maintaining stable spindle rotation.
- 6-Station Electric Tool Post: The 6-station electric tool post provides efficient tool selection and supports multiple turning operations within a single machining setup.
- Flexible CNC Control Options: GSK, FANUC, and Siemens CNC control systems can be configured according to customer production requirements.
- Centralized Automatic Lubrication System: The lubrication system supplies lubricant to guideways and moving components to help reduce wear and support long-term machine reliability.
For general information about machine guarding and safe operation, see the
OSHA Machine Guarding Guide.
Typical Machining Applications
Automotive Components
Suitable for machining wheel hubs, shafts, discs, sleeves, and other large rotating automotive components requiring stable CNC turning performance.
Mechanical Manufacturing
Ideal for producing large-diameter shafts, flanges, hubs, sleeves, and heavy mechanical parts used in industrial equipment.
Pump & Valve Industry
Suitable for turning pump components, valve bodies, flanges, sleeves, and cylindrical parts used in industrial fluid equipment.
General Machine Shops
A flexible CNC turning solution for custom machining, repair work, and small-to-medium batch production involving large-diameter components.
Factory Quality Assurance & Technical Support
- Laser Interferometer Calibration: Machine positioning and geometric accuracy can be checked using laser interferometer calibration before shipment.
- Sample Trial Cutting: Trial machining can be performed according to agreed inspection requirements before delivery.
- 72-Hour Continuous Running Test: The current CK6163 product specification states a 72-hour continuous operation test before dispatch.
- Inspection Documentation: Full inspection reports and pre-shipment videos can be provided before dispatch.
- Direct Manufacturer Support: ZCIT provides technical consultation, machine configuration recommendations, export support, and after-sales technical assistance.
Related CNC Lathe Machines
Explore our complete
CNC Lathe Machine Product Range
for more CNC turning solutions.
For other flat bed configurations, visit our
CNC Flat Bed Lathe Machines
category.
Need Detailed Quotation or Workpiece Evaluation?
Send us your workpiece technical drawings, diameter, machining length, material, weight, or processing requirements. Our engineering team will provide a tailored machining solution and recommend the appropriate CK6163 configuration.
FAQ
1. Quality Control & Inspection
Q: How do you ensure machine precision before shipment?
A: Every machine undergoes laser interferometer calibration, sample trial cutting, and a 72-hour continuous operation test. Full inspection reports and pre-shipment videos are provided before dispatch.
2. Payment Terms
Q: What are your accepted payment terms?
A: We accept T/T (Telegraphic Transfer). Standard payment terms are a 30% deposit upon order confirmation, with the remaining 70% balance due prior to shipment.
3. Lead Time & Delivery
Q: What is the estimated lead time for delivery?
A: Standard models are shipped within 20 to 30 days after deposit receipt. Customized machines or special configurations take 30 to 60 days depending on specs.
