CNC Laser Cutting Machine for Tube and Plate

The LCT3015 is a powerful CNC laser cutting machine for tube and plate
designed for manufacturers that need to process both flat metal sheets and metal tubes with
one machine. Its 2-in-1 configuration combines plate cutting and tube cutting capabilities,
helping manufacturers handle different fabrication requirements without purchasing separate
machines.

Equipped with a 3000W fiber laser source, the LCT3015 provides a
1500 × 3000 mm plate cutting area and a
240 × 240 × 6000 mm tube rotary axis. This combination makes the machine
suitable for sheet metal fabrication, tube processing, structural components and general
industrial metal cutting.

Key Features

• 2-in-1 tube and plate cutting: One CNC laser cutting machine processes both flat sheets and metal tubes.
• 3000W fiber laser source: Provides efficient cutting performance for industrial metal fabrication.
• 1500 × 3000 mm plate cutting area: Suitable for common sheet metal processing requirements.
• 240 × 240 × 6000 mm tube rotary axis: Supports long tube and pipe processing.
• 20 mm carbon steel capacity: Maximum specified cutting thickness for carbon steel.
• 12 mm stainless steel capacity: Maximum specified cutting thickness for stainless steel.
• 70 m/min maximum moving speed: Supports efficient CNC machine movement.
• 1G acceleration: Helps improve machine movement efficiency during production.

Technical Specifications of the LCT3015

2-in-1 Tube and Plate Laser Cutting

The main advantage of the LCT3015 is its combined tube and plate processing capability.
Instead of using separate equipment for sheet metal and tube fabrication, manufacturers
can use one CNC laser cutting machine for tube and plate applications.
This configuration can help reduce equipment investment and make better use of production
floor space.

Plate Laser Cutting

The machine provides a 1500 × 3000 mm plate cutting area for processing
flat metal sheets. The specified maximum cutting thickness is up to
20 mm for carbon steel and 12 mm for stainless steel,
depending on material and cutting conditions.

Tube and Pipe Laser Cutting

The integrated rotary axis provides a specified processing capacity of
240 × 240 × 6000 mm. It is designed for tube and pipe cutting applications
where long metal profiles need to be processed by a CNC laser system.

One Machine for Multiple Applications

By combining plate and tube cutting functions, the LCT3015 provides a flexible solution
for metal fabrication businesses that process different types of workpieces. The same
machine can be configured for flat sheet cutting and tube processing according to
production requirements.

Materials and Applications

This tube and plate laser cutting machine is designed for a wide range
of metal fabrication and manufacturing applications. Typical materials and workpieces
include:

• Carbon steel plates
• Stainless steel plates
• Square metal tubes
• Rectangular tubes
• Structural steel tubes
• Metal pipes
• Steel brackets and frames
• Fabricated machinery components

Typical Industrial Applications

• Metal fabrication workshops
• Structural steel manufacturing
• Machinery manufacturing
• Steel frame production
• Sheet metal fabrication
• Tube and pipe fabrication
• General industrial component production

CNC Laser Cutting Machine Configuration

The LCT3015 uses selected industrial components for CNC movement, positioning and
laser cutting operations. The specified configuration includes:

• Laser source: 3000W fiber laser.
• Guide rails: KOTEC, Taiwan.
• Rack: Vastun, Germany.
• Servo motor: Leadshine 750W.
• Reducer: Shimpo, Japan.
• Tube cutting system: 240 × 240 × 6000 mm rotary axis.
• Lubrication: Automatic oil injection system.

The machine is designed as a CNC-controlled cutting system for manufacturers that need
repeatable plate and tube processing in one production setup.

Why Choose a Tube and Plate CNC Laser Cutting Machine?

• Combined processing:
  Process both metal plates and tubes using one CNC laser cutting system.
• Flexible production:
  Switch between flat sheet and tube applications according to production needs.
• 3000W laser power:
  Provides strong cutting capability for industrial metal fabrication.
• Large plate capacity:
  The 1500 × 3000 mm working area accommodates common sheet metal sizes.
• Long tube processing:
  The rotary axis supports tubes up to 6000 mm in the specified configuration.
• High-speed movement:
  Maximum moving speed reaches 70 m/min with 1G acceleration.
